Building a multi-vessel brewing stand from welded steel is the project that transforms a homebrewing setup from a collection of equipment on the floor into a permanent, organized system. I welded my three-tier stand from 1.5″ square steel tubing over a weekend, and the improvement in brew day ergonomics, vessels at the right height, everything accessible, no bending over to check sight glasses, made every subsequent brew day better. The welding itself is straightforward for anyone with basic MIG or stick welding skills. The critical part is getting the geometry right before welding: measure twice, tack first, then complete the welds.
Stand design principles
Vessel height tiers
A three-tier gravity system stages vessels at different heights so wort flows by gravity through the process: HLT (hot liquor tank) at top, mash tun (MLT) at mid-height, boil kettle at floor level. Typical heights: HLT bottom at 60–66″, MLT bottom at 36–42″, BK bottom at 0–12″. The height difference between HLT and MLT must be sufficient for gravity fly sparging if that’s your process, a 12″+ drop with a 1/2″ supply line provides adequate flow rate. Pump-assisted systems (HERMS) don’t require gravity staging and can use equal-height shelves, but staggered heights simplify the plumbing and allow gravity backup if a pump fails.
Structural sizing
1.5″ × 1.5″ × 0.120″ wall square steel tubing handles the loads of a full homebrew system with significant safety margin. A 15-gallon vessel of water weighs ~130 lbs; the stand must hold three vessels plus plumbing, propane burners (if applicable), and the brewer leaning on it. For a three-vessel 15-gallon system, the total load is 500–600 lbs. A properly welded 1.5″ square tube frame with cross-bracing handles this load easily. Heavier (1/4″ wall) tubing is not needed and adds unnecessary weight. Avoid angle iron for primary structure, it has inferior torsional stiffness compared to square tube.
Weld plan and sequence
- Cut all pieces to length with a chop saw or angle grinder. Cut list for a basic 3-tier stand: 4 vertical legs (cut to height of HLT tier), 2 sets of horizontal shelf frames (rectangles sized to hold your vessel diameter + 4″ clearance each side), 4 diagonal braces per tier for rigidity.
- Build the shelf frames flat first. Lay two long horizontal rails and two short side rails on a flat surface. Clamp square. Tack weld all four corners. Verify diagonals are equal (confirms square). Complete corner welds.
- Assemble the vertical structure. Stand the legs vertically, set shelf frames at the correct heights, and tack weld. Check vertical plumb with a level at multiple angles. Adjust tacks before completing welds, once full welds are down, warping is difficult to correct.
- Add cross-bracing. Install X-bracing or diagonal braces on at least two sides of each tier opening. Without bracing, the stand racks (distorts under load) even if the welds are strong.
- Weld kettle supports. The bottom tier needs a flat platform or grate to hold the boil kettle on a burner. Upper tiers need a ring or rails sized to the vessel diameter that prevent the vessel from tipping but allow removal.
- Grind and clean welds. Smooth any sharp weld spatter. If the stand will be in an outdoor environment, prime and paint all steel surfaces to prevent rust.
Burner and electrical integration
For propane-fired stands: weld or bolt burner brackets at each tier to hold banjo burners in fixed position under each vessel. Route propane lines through the stand frame for a clean installation. For electric systems: mount an electrical box on the stand frame and run conduit from the box to heating element connections. Building the electrical system into the stand (rather than hanging it separately) creates a much cleaner, safer installation than exposed wire runs.
Common Questions
Should I use MIG or TIG welding for the stand?
MIG (GMAW) welding is ideal for this application, it’s fast, forgiving on mild steel, and produces structurally adequate welds even with moderate skill. Use ER70S-6 wire with 75/25 Ar/CO2 shielding gas. TIG is not necessary for a mild steel stand, though experienced TIG welders may prefer it for cosmetic welds. Stick (SMAW) welding works but is slower and less convenient for the tight inside corners of a frame. The most important welding practice for a stand is root fusion, make sure weld penetrates to the joint root and not just bridges across the surface. Test with a bend test on a sample joint: proper penetration will bend before the weld breaks; surface-only welds will crack at the weld toe immediately.
