A HERMS (Heat Exchange Recirculating Mash System) uses a heat exchanger coil submerged in the hot liquor tank to gently heat recirculating wort, the coil never exceeds the HLT water temperature, eliminating scorching risk while providing precise, PID-controlled mash temperature. I’ve used a HERMS coil for step mashing wheat beers and Belgian tripels where scorching at a direct heating element would be more likely due to the high adjunct content, and the gentle heating produces noticeably cleaner flavors than direct RIMS heat in these styles.
Building a HERMS system: coil design and three-vessel setup
HERMS system overview: A complete HERMS system has three vessels: the Hot Liquor Tank (HLT, heated water reservoir), the Mash/Lauter Tun (MLT, the insulated cooler or HERMS mash tun with false bottom), and the boil kettle. The HLT heats to the target temperature first (e.g., 68°C for a single-temp mash), then the pump draws wort from the MLT, passes it through the HERMS coil submerged in the HLT water, and returns heated wort to the MLT. The PID controller measures wort return temperature and adjusts HLT element cycling to maintain target mash temperature. Building the HERMS coil: The coil is typically 6–10 meters of 1/2-inch (12mm) stainless steel tubing (NOT copper, copper in the HLT would leach copper into the sparge water which then contacts wort) coiled to fit inside your HLT. Stainless 304 tubing is the correct material, available from stainless steel suppliers and homebrew equipment vendors. Coil the tubing around a cylinder form of appropriate diameter for your HLT interior. Allow 30–40cm of straight tubing at each end for connections through the HLT wall (use bulkhead fittings). Triclamp or threaded barb connections at each end. The longer the coil, the more heat transfer surface area, 6m is minimum adequate for a 20L batch HERMS; 10m is better for reliable temperature step performance. HLT heating element: A weld-in low-watt-density heating element (1500W for a 40L HLT) controlled by a PID, same setup as RIMS but heating the water rather than the wort directly. The lower watt density (power per unit area) of the HLT element reduces water scorching risk. Alternatively: an immersion coil heated by a gas burner for a non-electric HERMS. Temperature control strategy: Set PID to target mash temperature. Place probe at the return point (wort returning to MLT). PID controls HLT element to hold HLT temperature slightly above mash target (usually 2–5°C above to drive heat transfer). For step mashes: change PID setpoint, wait for HLT to reach new temperature, then monitor return wort until it reaches the step target. Plumbing: Use food-grade silicone tubing for all wort and hot water connections above 60°C. Standard vinyl tubing deforms above 60°C and can introduce off-flavors from plasticizer migration.
Common Questions
Can I build a HERMS system without a dedicated HLT?
A HERMS system without a dedicated HLT is technically possible but requires compromises that limit its functionality. The standard alternative is a “Brew-in-a-Bag HERMS” or “single-vessel HERMS”: a large pot (the boil kettle) serves as both HLT and eventually the boil vessel, and the HERMS coil is submerged in this pot during the mash phase. After lautering, the pot’s function transitions to boiling. This saves one vessel but requires the pot to be large enough to hold both sparge water and the HERMS coil alongside the grain bag. A simpler alternative to a full HERMS for temperature control without a dedicated HLT: use an insulated cooler mash tun (which passively maintains temperature with good retention) combined with occasional small hot water additions to adjust mash temperature when needed. This is the “step mashing by decoction-addition” approach, not as precise as HERMS but achieves 2-step mash profiles without the plumbing complexity. For homebrewers considering a HERMS build specifically for Indian brewing conditions: the HERMS complexity is warranted if you regularly brew wheat beers, Belgian-style ales with complex mash profiles, or historical beers requiring protein rests. For a typical all-malt ale or IPA brewer using single-infusion mashing, an insulated cooler mash tun with consistent water temperature (a thermometer and occasional hot water additions) achieves acceptable temperature stability at a fraction of the complexity and cost. Build to your actual brewing needs, a full HERMS three-vessel system is a multi-week, ₹20,000–50,000 project that is rewarding but disproportionate for a brewer who does 4 batches per year of single-infusion ales.
